Please see the relevant Televac ® EthernetIP product Instruction Manual for a full description on Class 1 and Class 3 connections, as well as a complete ADI table including data instance, name, array length, access, and description, and for information on configuring the IP Address. Before setting up a new connection, refer to Televac ® Application Note 3016 for loading an EDS file into the PLC and adding a new Ethernet module to the project. This will allow the PLC to communicate with the connected EthernetIP Televac ® device to exchange data and set parameters from a remote location. This application note explains the basics of the process for creating and mapping Class 3 Explicit Message connections in the Rockwell Automation Studio 5000 development environment for CompactLogix Programmable Logic Controllers (PLCs). National Labs, Research and Development.Liquefied Natural Gas (LNG), Industrial Gas, Cryogenics.Geotechnical Monitoring and Structural Monitoring.
